Standard Version Ratings: 10A125V 6(8)A250V 6(4)A250V
High Current Version Ratings: 16A125V 16A250V 10A250V 8/128A250V
Insulation Resistance: ≥ 100MΩ at 500V DC
Contact Resistance: ≤ 50mΩ
Dielectric Strength: 1500VAC (50–60Hz) for 1 minute
Operating Temperature: -10°C ~ 105°C
Solderability: 230±10°C for 3±1 seconds
Solder Heat Resistance:
255±5°C for 3±1 seconds(Reflow soldering) 350±10°C for 3±0.5 seconds(Manual soldering)
Cold Resistance: -20±2°C for 96 hours
Humidity Resistance: 40±2°C, 90–95% RH for 96 hours
Mechanical Life: 10,000 cycles
