Ratings: 16A 250V, 12A 250V, 15A 125V
Insulation Resistance: ≥ 100 MΩ at 500V DC
Contact Resistance: ≤ 50 mΩ
Dielectric Strength: 500VAC (50–60Hz) between terminals for 1 minute
Operating Temperature: -10℃ to 105℃
Solderability: 230±10℃ for 3±1 seconds
Solder Heat Resistance: 255±5℃ for 3±1 seconds (wave soldering), 350±10℃ for 3±0.5 seconds (manual soldering)
Cold Resistance: -20±2℃ for 96 hours
Humidity Resistance: 40±2℃, 90–95% RH for 96 hours
Mechanical Life: 10,000 cycles
